The TORS is the Throttle Override System. It’s mainly the little black box above the left carb, simply unplug it to deactivate it. It is supposed to electronically reduce the throttle if the throttle sticks open but most people remove it because its usually the route of many problem’s. Quick answer for removal The black box is just above the left exhaust and is about 1.5"x1" and has a 3 ...
yes the tors will create a no spark. you have it backwards for the jumper, the tors is the 2 wires and the tps is the three. unplug the tps and the machine defaults to the wot timing curve and jump the 2 tors wires. here is the original post. the whole post is 08 yfz wont start. ignore the carb stuff i just copy and pasted the writeup.
I had read a post on Hot Wiring tht TORS so you disactivate it. How can this be done without buying a TORS removal kit???? I remeber somthing like you splice some wires together.
The TORS is designed to cut the ignition if the throttle cable gets stuck and it's revving out. There's a switch in the throttle assembly and another one in the idle adjuster on top of the carb.
TORS is the Throttle OverRide System found on stock Banshees. It consists of the large boxy carb tops, a switch on the thumb throttle housing, a switch on the parking brake perch, and a control box mounted to the frame rail above the left cylinder.
The tors system can be bypassed by cutting the wires that go into the switch on the throttle and connecting them together. I had to do this when I put on the 400ex throttle.
